Corner Crimping Machine (LZJ4-CNC-1800x3000)

Features:

Used for corner punching and riveting combination, four corners connecting at one time are available.

Clamping device can move front and back automatically, easily operation.

Wide profile processing range due to convenient corner combining cylinder setting.

High helical pitch ball screw-lead controls head feeding, high accuracy.

Imported CNC system, which include PLC, touched screen, servomotor,

and servo driver, photoelectrical switch, and photoelectrical cells etc.

Technical Parameters:

Input voltage：                   380V/50Hz

Input power：                     7.5kw

Air pressure：                    0.5~0.8MPa

Input power：                     3kw

Air consumption：              0.45 L/Time

Hydraulic pressure：         15 Mpa

Oil capacity：                     40L

Max. Profile width：           100mm

Max. Dimension：              1800*3000mm

Min. Dimension：               560*560mm

Overall dimension：           4700*2000*2600mm.
