Corner Cleaning Machine SQJ01-120

Features：

Used for cleaning the 90° Corner of welding seam (upper, lower surface and outer vertical surface).

Adjusting simply, processing accurately and clamping reliably.

Clamp once can clean the welding seams (upper, lower and outer vertical surface) so as to achieve
good appearance.

Technical Parameters:

Input voltage：                   380V/50Hz

Input power：                     1.1Kw

Air pressure：                    0.4~0.6MPa

Air consumption：              50L/min

Motor rotating speed：       2800r/min

Profiles width：                   20~120mm

Profiles height：                 20~120mm

Groove width：                   3mm

Groove depth：                  0.3mm

Overall dimension：           1050*670*1370mm
